Aorita HTF Film: Performance Test Report & Quality Verification

Aorita HTF Film: Performance Test Report & Quality Verification

  1. Introduction: What is Aorita HTF Film? Aorita HTF (High-Temperature Film) is a high-performance, heat-resistant release film designed for advanced 3D printing, industrial manufacturing, and high-temperature applications. Every batch undergoes rigorous quality control testing to ensure consistent performance, reliability, and safety. Below is a detailed, SEO-optimized breakdown of the test results for Batch FMK202412, highlighting the key specifications, test values, and benefits for end-users. 2. Core Performance Test Results (Batch FMK202412) All tests were conducted according to international standards, with 100% passing results across all critical parameters. 2.1 Dimensional Stability & Precision

    2. Core Performance Test Results (Batch FMK202412)


    All tests were conducted according to international standards, with 100% passing results across all critical parameters.

    Test Parameter Specification Test Result Status
    Thickness Tolerance 0.2mm ±10% 0.2 ±0.01mm ✅ Pass

    2.1 Dimensional Stability & Precision

    Key Benefit: Ultra-tight thickness tolerance ensures uniform flatness, eliminating uneven pressure or warping in high-precision 3D printing and lamination processes. This consistency directly improves print accuracy and reduces failed parts.
  2. 2. Mechanical Strength & Durability
    Test Parameter Specification Test Result Status
    Tensile Strength >40 MPa TD: 76.66 MPa / MD: 81.12 MPa ✅ Pass
    Elongation at Break >100% TD: 140% / MD: 116% ✅ Pass

Key Benefit: Industry-leading tensile strength and elongation make the film tear-resistant, even when removing large or complex 3D printed parts. It withstands repeated use without cracking or degrading, extending its service life.

2.3 Optical Clarity & Transmittance

Test Parameter Specification Test Result Status
Light Transmittance >90% 91.86% ✅ Pass

Key Benefit: High light transmittance (91.86%) ensures uniform UV light penetration in resin 3D printing, enabling precise curing, sharp details, and consistent print quality. This makes it ideal for SLA/DLP/LCD printers requiring high resolution.

2.4 Surface Properties for Smooth Release

Test Parameter Specification Test Result Status
Dynamic Friction Coefficient <0.5 0.2 ✅ Pass
Static Friction Coefficient <0.06 0.04 ✅ Pass
Water Contact Angle >100° 114° ✅ Pass



Key Benefit: Ultra-low friction coefficients and a high hydrophobic contact angle (114°) ensure effortless part release. Prints peel off cleanly without sticking or damage, reducing post-processing work and improving user experience.

2.5 Thermal Stability for High-Temperature Applications

Test Parameter Specification Test Result Status
Melting Point 310°C 310°C ✅ Pass
Long-Term Working Temperature 260°C 260°C ✅ Pass



Key Benefit: A high melting point of 310°C and continuous working temperature of 260°C make HTF Film suitable for high-temperature 3D printing (e.g., PEEK, PEKK, ULTEM) and industrial processes. It remains dimensionally stable and does not degrade under prolonged heat exposure.

2.6 Chemical & Safety Performance

Test Parameter Specification Test Result Status
Drug Resistance - Pass ✅ Pass
Appearance (Impurities) No foreign matter No foreign matter or impurities ✅ Pass
Flame Retardancy - UL 94V0 ✅ Pass



Key Benefit: Excellent chemical resistance protects against degradation from resins, solvents, and cleaning agents. UL 94V0 flame retardancy certification adds an extra layer of safety for industrial and commercial use cases.

3. Why Aorita HTF Film Stands Out: Key Advantages


  • Consistent Quality: Every batch undergoes full testing to meet strict standards, ensuring reliability for every print or application.
  • High-Temperature Compatibility: Rated for continuous use up to 260°C, ideal for engineering-grade materials and industrial processes.
  • Easy Release & Low Maintenance: Low-friction, hydrophobic surface minimizes sticking and part damage, saving time and material waste.
  • Durable & Long-Lasting: Superior mechanical strength and chemical resistance extend the film’s lifespan, reducing replacement costs.
  • Safety Certified: UL 94V0 flame retardant, suitable for commercial, industrial, and educational environments.


4. Applications of Aorita HTF Film


Aorita HTF Film is designed for use across multiple industries, including:

  • Resin 3D printing (SLA/DLP/LCD/MSLA)
  • High-temperature FDM 3D printing (PEEK, PEKK, ULTEM)
  • Industrial lamination and molding processes
  • Electronics manufacturing and assembly
  • Laboratory and research applications


5. Custom HTF Film Solutions


If you have specific requirements for thickness, surface properties, or dimensions, Aorita offers custom HTF film solutions tailored to your project needs. Contact our team to discuss your specifications and request a free sample.
